Octudex · Comprehensive Catheter Partner

one partnerevery catheterOctudex·From medical tubing to finished catheters

LinstantAuthorized Korea distributor

Octudex is the official Korean distributor of Ningbo Linstant Polymer Materials, supplying precision catheter tubing — PEEK, PI, PTFE liner, heat shrink, braided tubing — from an ISO 13485 plant to Korean device makers. Spec review in Korean, first reply within one business day.

Request a quoteSee the range
Catheter shaft printed with graduation bands
Catheter shaft printed with graduation bands

Linstant builds it, Octudex supplies it

Ningbo Linstant Polymer Materials
Manufacturing
Polymer tubing extrusion and processing
Ningbo, China
Octudex
Korea distribution
Supply · technical support · after-sales
Seoul, Korea
Facilities, certifications and history are on the About page.About the company →

Where Linstant tubing goes

Linstant supply record · published sources
MicroPortLifetech ScientificLepu MedicalVenus MedtechMicro-TechPeijia MedicalHanyu Medical

Major customers published by Linstant (linstants.com). Korean supply references are not disclosed without customer consent; similar cases are shared on inquiry.

Medical Tubing

Medical Tubing
18 rows

We extrude PEEK, PI, PTFE, FEP, PEBAX and TPU, and reinforce with braid and coil. Inner diameter 0.10–23.00 mm, reinforced tubing 1.7–39 Fr, tolerance from ±0.01 mm. We do not sell part numbers — we build to your drawing.

Catheter shafts with marker bands — extrusion, braid, marker banding
Shafts run through extrusion, braiding, marker banding and printing on a single order
Items
Dimensions mm
Tolerance mm
Wall mm
Construction · notes
Extruded tubing · liners 7
0.10–23.00
—
—
PP · PC · PE · PA · TPU · PEBAX
ID 0.10–23.00
±0.03
0.05–3.00
18 dedicated lines
ID 0.10–5.00
≤0.01
0.02
Thermoset
OD 0.20–18.00
±0.01
0.05–1.00
Nylon · Pebax · PU · TPU · PET
ID 0.10–6.50
±0.01
0.01–0.08
Extrusion · co-extrusion
ID 3.41 delivered
—
0.03
PFAS-free
ID 0.30–12.70
—
0.006–0.50
FEP · PE · PEBAX · PEEK · PET
Reinforced 4
1.7–39 Fr
±0.0127–0.0254
—
PA·PEBAX·TPU / SS·Nitinol / PTFE·PEEK
1.7–39 Fr
±0.0127–0.0254
—
Same three-layer build
ID 0.10–4.00
±0.01
0.01–0.15
PI·PEBAX·PA / 304SS / PTFE·PI
OD 0.8–6.8
—
—
TPU·PA12·PEBAX / SS / PTFE·PVDF
Finished devices · OEM 8
—
—
—
304SS or LCP pull wire
Distal 2.1–2.7 Fr
—
—
PTFE inner surface · Pt-Ir marker
5–8 Fr
±0.03
—
PTFE liner + 304SS braid
4 · 5 · 6 Fr
—
—
PEBAX + SS braid
9.5–14 Fr
±0.05
—
304SS 0.08 × 0.3 · hydrophilic coating
—
—
0.1~
TPU family 80A–85D
Extruded tubing · liners7 items
Dimensions0.10–23.00 mm
PP · PC · PE · PA · TPU · PEBAX
Full specification →
DimensionsID 0.10–23.00 mmTolerance±0.03 mmWall0.05–3.00 mm
18 dedicated lines
Full specification →
DimensionsID 0.10–5.00 mmTolerance≤0.01 mmWall0.02 mm
Thermoset
Full specification →
DimensionsOD 0.20–18.00 mmTolerance±0.01 mmWall0.05–1.00 mm
Nylon · Pebax · PU · TPU · PET
Full specification →
DimensionsID 0.10–6.50 mmTolerance±0.01 mmWall0.01–0.08 mm
Extrusion · co-extrusion
Full specification →
DimensionsID 3.41 mm deliveredWall0.03 mm
PFAS-free
Full specification →
DimensionsID 0.30–12.70 mmWall0.006–0.50 mm
FEP · PE · PEBAX · PEEK · PET
Full specification →
Reinforced4 items
Dimensions1.7–39 FrTolerance±0.0127–0.0254 mm
PA·PEBAX·TPU / SS·Nitinol / PTFE·PEEK
Full specification →
Dimensions1.7–39 FrTolerance±0.0127–0.0254 mm
Same three-layer build
Full specification →
DimensionsID 0.10–4.00 mmTolerance±0.01 mmWall0.01–0.15 mm
PI·PEBAX·PA / 304SS / PTFE·PI
Full specification →
DimensionsOD 0.8–6.8 mm
TPU·PA12·PEBAX / SS / PTFE·PVDF
Full specification →
Finished devices · OEM7 items
304SS or LCP pull wire
Full specification →
DimensionsDistal 2.1–2.7 Fr
PTFE inner surface · Pt-Ir marker
Full specification →
Dimensions5–8 FrTolerance±0.03 mm
PTFE liner + 304SS braid
Full specification →
Dimensions4 · 5 · 6 Fr
PEBAX + SS braid
Full specification →
Dimensions9.5–14 FrTolerance±0.05 mm
304SS 0.08 × 0.3 · hydrophilic coating
Full specification →
Wall0.1 mm and up
TPU family 80A–85D
Full specification →
Item detail · applications →

Secondary Processing

Secondary Processing
on the same order

Braid and coil reinforcement, reflow, tip forming, hole punching, marker bands, hydrophilic coating, laser printing. We finish extruded tube to one step short of a finished device, all in the same ISO 7 cleanroom.

Braiding 16 · 24 · 32 carriersCoil windingReflowThree-layer co-extrusionTip forming up to 70 mmHole punchingMarker bandTaper · diameter changePTFE etchingHydrophilic coatingLaser printingInjection molding
See every process →

Company

Company
Founded 2014 · ISO 13485
Linstant×Octudex

42,300 ㎡ of plant in Ningbo, 12,000 ㎡ of ISO 7 cleanroom, ISO 13485. Linstant, founded 2014, builds it; in Seoul, Octudexhandles technical support, samples, customs and quality response.

42,300㎡
3 manufacturing sites
12,000㎡
ISO 7 cleanroom
500+
Employees
About the company →
ISO 7 cleanroom production line
ISO 7 cleanroom · Ningbo · 12,000 ㎡
NewPFAS-free liner

Replacing PTFE liner
with UHMWPE

If PFAS regulation has you evaluating fluoropolymer alternatives, samples are available now. In the same size range as etched PTFE liner, wear resistance is better.

2025 Strategic cooperation with DSM — jointly developing UHMWPE+TPU materials for long-term implants.
More on UHMWPE liner
UHMWPE liner samples — clear and white

Technical notes

Technical Notes

Where PA gives way to PI, how to divide the layers, what PEEK biocompatibility actually covers. The judgement calls a design engineer has to make, written up in Korean.

2026.09.16PA vs PI — choosing a catheter material2026.09.09Catheter design guide — material, layers, tolerance2026.09.02PEEK biocompatibility — what an engineer should know
All technical notes →
Contact

Send us a specification
and we answer feasibility first

Dimensions, material, application. Those three are enough to start. A drawing makes it faster. Anything not in the published material we check directly with Ningbo.

grit@octud.com010-3338-2976
01Dimensions — mm or Fr · OD / ID / wall
02Material or required properties
03Application · expected volume · whether secondary processing is needed
Support in Korean and English · drawings welcomeSend an inquiry
